Standard Hoses:

straight Reducer























No.

Bore 1 (mm)

Bore 2 (mm)

Wall Size (mm)

Ply

Length (mm)













1

16

13

3.5

3

102

2

19

13

3.5

3

102

3

19

16

3.5

3

102

4

22

16

3.5

3

102

5

22

19

3.5

3

102

6

28

22

3.5

3

102

7

28

25

3.5

3

102

8

32

25

3.5

3

102

9

32

28

3.5

3

102

10

35

25

3.5

3

102

11

35

28

3.5

3

102

12

35

32

3.5

3

102

13

38

22

3.5

3

102

14

38

25

3.5

3

102

15

38

28

3.5

3

102

16

38

32

3.5

3

102

17

38

35

3.5

3

102

18

41

35

3.5

3

102

19

45

32

3.5

3

102

20

45

38

3.5

3

102

21

51

38

5

4

102

22

51

45

5

4

102

23

54

51

5

4

102

24

57

51

5

4

102

25

60

50

5

4

125

26

63

51

5

4

125

27

70

50

5

4

125

28

70

57

5

4

125

29

70

60

5

4

125

30

76

51

5

4

125

31

76

63

5

4

125

32

76

67

5

4

125

33

80

70

5

4

125

34

90

80

6

4

125

35

102

76

6

4

152

Standard Elbow (45', 90', 135')







No.

Bore (mm)

Wall Size (mm)

Ply

Leg Length (mm)











1

6.5

3.5

3

63

2

8

3.5

3

63

3

9.6

3.5

3

63

4

11

3.5

3

63

5

13

3.5

3

102

6

16

3.5

3

102

7

19

3.5

3

102

8

22

3.5

3

102

9

25

3.5

3

102

10

28

3.5

3

102

11

30

3.5

3

102

12

32

3.5

3

102

13

35

3.5

3

102

14

38

3.5

3

102

15

41

3.5

3

102

16

45

3.5

3

102

17

48

5

4

102

18

51

5

4

102

19

54

5

4

102

20

57

5

4

102

21

60

5

4

125

22

63

5

4

125

23

65

5

4

125

24

70

5

4

125

25

76

5

4

125

26

80

5

4

125

27

83

5

4

125

28

89

6

5

125

29

90

6

5

125

30

102

6

5

152

Straight Hose (one meter in length)

No.

Bore (mm)

Wall Size (mm)

Ply(s)

1

6.5

3.5

3

2

8

3.5

3

3

9.5

3.5

3

4

11

3.5

3

5

13

3.5

3

6

16

3.5

3

7

19

3.5

3

8

22

3.5

3

9

25

3.5

3

10

28

3.5

3

11

30

3.5

3

12

32

3.5

3

13

35

3.5

3

14

38

3.5

3

15

41

3.5

3

16

45

3.5

3

17

48

5

4

18

51

5

4

19

54

5

4

20

57

5

4

21

60

5

4

22

63

5

4

23

65

5

4

24

68

5

4

25

70

5

4

26

76

5

4

27

80

5

4

28

83

5

4

29

89

6

5

30

102

6

5
